Radeon graphics cards have varying power usage depending on the specific model and its performance capabilities. Generally, higher-end models with more advanced features and higher clock speeds will require more power to operate than lower-end models.
AMD, the company behind Radeon graphics cards, has developed a technology called PowerTune that helps manage power consumption and optimize performance. PowerTune technology adjusts the power draw of the graphics card based on its workload, ensuring that it uses only the necessary amount of power to deliver optimal performance.
In addition, many Radeon graphics cards feature energy-efficient technologies such as AMD’s ZeroCore Power technology, which reduces power consumption when the graphics card is idle, and AMD’s PowerPlay technology, which adjusts power usage based on the graphics card’s performance profile.
It is important to note that power usage can also be affected by factors such as the user’s computer configuration and settings, as well as the workload of the specific application or game being run. It is always recommended to refer to the manufacturer’s specifications and guidelines for proper power usage and management of Radeon graphics cards.
GPU | Power Rating (Watts) |
---|---|
Radeon 7200 | 18W |
Radeon 7500 | 22W |
Radeon 7500LE | 22W |
Radeon 8500 | 30W |
Radeon 8500LE | 28W |
Radeon 9000 | 28W |
Radeon 9000 Pro | 28W |
Radeon 9100 | 28W |
Radeon 9100 Pro | 28W |
Radeon 9200 | 28W |
Radeon 9200 Pro | 28W |
Radeon 9200LE | 28W |
Radeon 9200SE | 23W |
Radeon 9250 | 20W |
Radeon 9500 | 40W |
Radeon 9500 Pro | 40W |
Radeon 9550 | 25W |
Radeon 9550SE | 25W |
Radeon 9600 | 22W |
Radeon 9600 Pro | 22W |
Radeon 9600LE | 22W |
Radeon 9600SE | 22W |
Radeon 9600XT | 22W |
Radeon 9700 | 81W |
Radeon 9700 Pro | 81W |
Radeon 9700TX | 81W |
Radeon 9800 | 77W |
Radeon 9800 Pro | 77W |
Radeon 9800SE | 77W |
Radeon 9800XT | 77W |
Radeon HD 2400 Pro | 20W |
Radeon HD 2400XT | 25W |
Radeon HD 2600 Pro | 45W |
Radeon HD 2600XT | 75W |
Radeon HD 2900 Pro | 135W |
Radeon HD 2900GT | 105W |
Radeon HD 2900XT | 165W |
Radeon HD 3450 | 25W |
Radeon HD 3470 | 25W |
Radeon HD 3650 | 65W |
Radeon HD 3850 | 105W |
Radeon HD 3870 | 135W |
Radeon HD 3870X2 | 230W |
Radeon HD 4350 | 20W |
Radeon HD 4550 | 25W |
Radeon HD 4650 | 48W |
Radeon HD 4670 | 59W |
Radeon HD 4770 | 80W |
Radeon HD 4830 | 110W |
Radeon HD 4850 | 110W |
Radeon HD 4850X2 | 225W |
Radeon HD 4860 | 90W |
Radeon HD 4870 | 150W |
Radeon HD 4870X2 | 250W |
Radeon HD 4890 | 190W |
Radeon HD 5450 | 19W |
Radeon HD 5550 | 39W |
Radeon HD 5570 | 43W |
Radeon HD 5670 | 61W |
Radeon HD 5750 | 86W |
Radeon HD 5770 | 108W |
Radeon HD 5830 | 175W |
Radeon HD 5850 | 151W |
Radeon HD 5870 | 188W |
Radeon HD 5870 EF6 | 188W |
Radeon HD 5970 | 294W |
Radeon HD 6350 | 19W |
Radeon HD 6450 | 27W |
Radeon HD 6570 | 60W |
Radeon HD 6670 | 66W |
Radeon HD 6750 | 86W |
Radeon HD 6770 | 108W |
Radeon HD 6790 | 150W |
Radeon HD 6850 | 127W |
Radeon HD 6870 | 151W |
Radeon HD 6930 | 200W |
Radeon HD 6950 | 225W |
Radeon HD 6970 | 250W |
Radeon HD 6990 | 375W |
Radeon HD 7350 | 19W |
Radeon HD 7450 | 18W |
Radeon HD 7470 | 49W |
Radeon HD 7570 | 50W |
Radeon HD 7670 | 66W |
Radeon HD 7750 | 55W |
Radeon HD 7770 GHz Ed. | 80W |
Radeon HD 7790 | 85W |
Radeon HD 7850 | 130W |
Radeon HD 7870 GHz Ed. | 175W |
Radeon HD 7870 XT | 175W |
Radeon HD 7950 | 200W |
Radeon HD 7950 Boost | 225W |
Radeon HD 7970 | 250W |
Radeon HD 7970 GHz Ed. | 250W |
Radeon HD 7990 | 375W |
Radeon LE | 23W |
Radeon R7 240 | 30W |
Radeon R7 250 | 65W |
Radeon R7 250E | 55W |
Radeon R7 250X | 80W |
Radeon R7 260 | 95W |
Radeon R7 260X | 115W |
Radeon R7 265 | 150W |
Radeon R7 360 | 100W |
Radeon R7 370 | 140W |
Radeon R9 270 | 150W |
Radeon R9 270X | 180W |
Radeon R9 280 | 225W |
Radeon R9 280X | 250W |
Radeon R9 285 | 190W |
Radeon R9 290 | 275W |
Radeon R9 290X | 290W |
Radeon R9 295X2 | 500W |
Radeon R9 370X | 150W |
Radeon R9 380 | 225W |
Radeon R9 380X | 250W |
Radeon R9 390 | 275W |
Radeon R9 390X | 350W |
Radeon R9 Fury | 275W |
Radeon R9 Fury X | 350W |
Radeon R9 Nano | 175W |
Radeon R9 Pro Duo | 450W |
Radeon RX 460 | 75W |
Radeon RX 470 | 150W |
Radeon RX 470D | 120W |
Radeon RX 480 | 150W |
Radeon RX 5300 | 100W |
Radeon RX 5300XT | 100W |
Radeon RX 540 | 35W |
Radeon RX 550 | 50W |
Radeon RX 5500XT | 130W |
Radeon RX 560 | 100W |
Radeon RX 560 | 80W |
Radeon RX 5600XT | 150W |
Radeon RX 560XT | 80W |
Radeon RX 570 | 150W |
Radeon RX 5700 | 180W |
Radeon RX 5700XT | 225W |
Radeon RX 580 | 225W |
Radeon RX 580 | 185W |
Radeon RX 590 | 225W |
Radeon RX 6500XT | 150W |
Radeon RX 6600 | 130W |
Radeon RX 6600XT | 160W |
Radeon RX 6650XT | 130W |
Radeon RX 6700 | 230W |
Radeon RX 6700XT | 230W |
Radeon RX 6750XT | 150W |
Radeon RX 6800 | 250W |
Radeon RX 6800XT | 300W |
Radeon RX 6900XT | 300W |
Radeon RX 6950XT | 330W |
Radeon RX 7900XT | 330W |
Radeon RX 7900XTX | 365W |
Radeon RX Vega 56 | 210W |
Radeon RX Vega 64 | 295W |
Radeon RX Vega 64 (Liquid) | 345W |
Radeon VE (7000) | 20W |
Radeon VII | 300W |
Radeon X1050 | 23W |
Radeon X1300 | 31W |
Radeon X1300 Pro | 31W |
Radeon X1300XT | 44W |
Radeon X1550 | 27W |
Radeon X1600 Pro | 43W |
Radeon X1600XT | 48W |
Radeon X1650 | 44W |
Radeon X1650 Pro | 44W |
Radeon X1650GT | 44W |
Radeon X1650XT | 44W |
Radeon X1800GTO | 75W |
Radeon X1800XL | 100W |
Radeon X1800XT | 100W |
Radeon X1900 | 100W |
Radeon X1900GT | 75W |
Radeon X1900XT | 125W |
Radeon X1900XTX | 135W |
Radeon X1950 Pro | 80W |
Radeon X1950GT | 60W |
Radeon X1950XT | 90W |
Radeon X1950XTX | 120W |
Radeon X300 | 25W |
Radeon X300SE | 24W |
Radeon X300SE HyperMemory | 35W |
Radeon X550 | 33W |
Radeon X600 Pro | 37W |
Radeon X600XT | 37W |
Radeon X700 | 43W |
Radeon X700 Pro | 47W |
Radeon X700LE | 41W |
Radeon X700XT | 47W |
Radeon X800 | 47W |
Radeon X800 Pro | 44W |
Radeon X800GT | 38W |
Radeon X800GTO | 38W |
Radeon X800SE | 38W |
Radeon X800XL | 44W |
Radeon X800XT | 49W |
Radeon X800XT Platinum Ed. | 49W |
Radeon X850 Pro | 53W |
Radeon X850XT | 51W |
Radeon X850XT Platinum Ed. | 51W |
Please leave a comment if there are any errors in power ratings.
